News — Education

What is the Centerline Radius (CLR) of a Bend?

Education Mandrel Bends Tight Radius Mandrel Bends

Centerline Radius of a Bend Example | Ace Race Parts

When fabricating a set of headers, a downpipe, or an exhaust one very critical dimension to pay attention to is the Centerline Radius of the bend. If the CLR of the bend is too "tight" or too "loose" for the application the end result might mean that the fabricated item may not fit the application properly, or it may mean that the inlet or outlet of the fabricated item will be way out of alignment.

Read more →


Interlock Liner Flex Coupling Data - Max Temperature / Max Angle

304 Stainless Education Exhaust Flex Couplings

Exhaust Flex Coupling Stainless Steel | Ace Race Parts

We are often asked about the Maximum Operating Temperature and the Maximum Axial Deflection Angle, or the maximum angle of movement, our Flex Couplings are able to handle. The maximum axial deflection angle that our Flex Coupling are able to handle is directly related to the overall length of the coupling itself. For shorter lengths, like our 4" overall length couplings, the maximum angle is 3°. For longer couplings, like our 10" overall length couplings, the maximum angle is quite a bit higher at 9°. Below is a table that shows both the maximum axial deflection angle, as well as the maximum operating temperature for all of our Flex Couplings.

Read more →


How to Measure a V-Band Flange

Education News V-Band Clamps and Flanges V-Band Flange Dimensions

V-Band Flange Apex Width | Ace Race Parts
We know that finding a compatible replacement V-Band Clamp or Flange for an existing product or application can be quite difficult and one of the most common questions we hear from new and existing customers is, “Why is finding a replacement V-Band component so difficult?” We hope that the information provided below will be useful for finding a matching replacement component for your V-Band Clamp or Flanges.

Read more →


V-Band Flange and Clamp Dimensions — CP2 Titanium, Titanium/Stainless Combination

Education Stainless Steel V-Band Clamps and Flanges V-Band Flange Dimensions

Ace Race Parts Titanium V-Band Assemblies are precision CNC machined in an ISO 9001 certified facility and feature a 304 Stainless Steel V-Band Clamp and a set of CP2 Titanium "Male/Female" interlocking style V-Band Flanges. Stainless Steel V-Band Clamps and Titanium Flanges are an affordable and durable type of clamping system that is suited for high performance automotive, diesel, marine and industrial applications.

Read more →


V-Band Flange and Clamp Dimensions — 304 Stainless, Mild Steel, MS/SS Combination

Education Stainless Steel V-Band Clamps and Flanges V-Band Flange Dimensions

Ace Race Parts V-Band Assemblies are precision CNC machined in an ISO 9001 certified facility and feature a 304 Stainless Steel V-Band Clamp and a set of "Male/Female" interlocking style V-Band Flanges. Stainless Steel V-Band Clamps and Flanges are an affordable and durable type of clamping system that is suited for high performance automotive, diesel, marine and industrial applications.

Read more →
