Our Aluminum weld bungs are precision CNC machined, in an ISO 9001 certified facility, from 6061-T6 Aluminum billet and are available in both Male and Female configurations and in sizes ranging from -4AN to -20AN, as well as NPT sizes.
-10AN Weld Bungs feature a standard 37° flared seating surface and 3/4"-16 SAE Female Thread. Our Aluminum Weld Bungs are a high quality, affordable choice for aluminum radiators, oil pans, tanks, and other custom fabrication projects.
DETAILED SPECIFICATIONS:
Material Size | -10AN |
SAE Thread | 7/8"-14 |
Thread Type | Female |
Shoulder OD | 1.338" |
Body OD | 1.180" |
Height |
0.656" |
Material Type | 6061-T6 Aluminum |
