HD Clamp Flange Set for 4.000" OD Tubing, 6061 Aluminum, FKM O-Rings

SKU 13236
39 in stock, ready to be shipped
Original price $ 39.99 - Original price $ 39.99
Original price
$ 39.99
$ 39.99 - $ 39.99
Current price $ 39.99

Product Dimension Info

Detailed product dimensions can be found on the main product page. If you need further assistance with product dimensions please email us at your convenience.

NOTE: Due to dimensional differences this specific 4.000" HD Clamp component is NOT cross-compatible with Vibrant Performance SKU 12548.

The Ace Race Parts brand of HD Clamp Flanges, or Weld Ferrules, are precision CNC machined from 6061 Aluminum and are provided with a set of FKM High Temperature O-Rings. When paired with our HD Clamps and HD Clamp Union Sleeves, our Aluminum HD Clamp Weld Ferrules allow for up to 12 degrees of axial and angular deflection.


  • Burst Pressure Rating: 800 psi
  • Temperature Rating: 400°F / 204°C
  • Axial Movement, Angular Deflection: Up to 12°
  • Full 6061 Aluminum Billet Construction


  • Two (2) 6061 Aluminum Weld Flanges
  • Two (2) FKM High Temperature O-Rings (Green Fluororubber)
