4.000" V-Band Assembly "Male/Female" 304 Stainless - Quick Release Clamp - Ace Race Parts

4.000" V-Band Assembly "Male/Female" 304 Stainless - Quick Release Clamp

SKU:
Brand: Ace Race Parts
$ 50.60

/ each


Our Quick-Release V-Band Assemblies utilize a 304 stainless clamp and flanges. Our "Male/Female" flanges have an interlocking seating surface to ensure proper alignment during installation. The butt-weld side of the flanges offer a small groove that allows the flange and tube to be aligned better prior to welding. Each assembly includes one (1) t-bolt style clamp and two (2) interlocking flanges.

Please note: Our V-Band clamps are supplied with a nylon lock nut. This type of nut is a locking-style nut and is not intended to be used during mock-up. Attempting to thread, remove, and re-threaded the lock nut may cause damage to the "T-Bolt" section of the clamp. In some cases, excessive force can damage and/or break the "T-Bolt" section of the clamp. If you intend to use our clamps during the mock-up process please use a standard finished hex nut (non-locking).

Ace Race Parts is not responsible for damage caused to our clamps due to the use of the locking-style nut during mock-up or removal.

DETAILED SPECIFICATIONS:
Flange ID 4.000"
Flange OD 4.739"
Individual Flange Thickness (Single Flange) 0.845"
Clamp Bandwidth
0.750"
Clamp Type V-Band, Quick Release T-Bolt
Material Type 304 Stainless
