2.500" 16ga 60° Mandrel Bend 6061 Aluminum - (3.750" CLR / 7.000" Legs) | Ace Race Parts

2.500" OD 16ga 60° Mandrel Bend - Polished OD - 6061 Aluminum - (3.750" CLR / 7.000" Legs)

Brand: Ace Race Parts
In Stock: 46 Pieces
$ 24.65

/ each

Ace Race Parts Aluminum mandrel bends are manufactured using 6061 Aluminum tubing and are precision bent using a CNC mandrel bender in an ISO certified facility to ensure a high quality bend across a wide range of shapes and sizes. Our Aluminum mandrel bends are available in 30°, 45°, 60°, 90°, and 180° bend options with outside diameters ranging from 1.500" to 4.000". Our mandrel bends are de-burred, cleaned, and highly polished to ensure a clean finish on the ends and the surface of the bend.

Our mandrel bends are a perfect match for our Aluminum Tube, Aluminum V-Band Clamps and Flanges, 4-Ply Silicone Couplings, and Stainless Steel T-Bolt Clamps

Outside Diameter 2.500"
Wall Thickness 16ga (0.065")
Inside Diameter 2.370"
Centerline Radius 3.750"
Leg Length 7.000"
Connection Type Tube OD Butt-Weld
Finish Polished and Buffed
Material Type 6061 Aluminum
